5/16" OD x 3/16" ID Un-reinforced Flexible PVC Tube, Clear Colour

SBR-E-T-160097

5/16" OD x 3/16" ID Un-reinforced Flexible PVC Tube, Clear Colour

In Stock
5/16" OD x 3/16" ID Un-reinforced Flexible PVC Tube, Clear Colour – 30M
£42.41+ VAT
Quantity
Price
1 - 9
£42.41
10 - 19
£36.05
20 - 29
£31.81
30
£27.57
SBR Life Sciences reserve the right to amend pricing in line with currency fluctuations.
Looking to purchase a large quantity? Click here

Description 5/16" OD x 3/16" ID Un-reinforced Flexible PVC Tube, Clear Colour – 30M

Extended Description 30M coil (100 Feet) of Un-reinforced flexible Clear Colour Polyvinyl Chloride (PVC) tube with an outside diameter of 5/16", an internal diameter of 3/16" and a wall thickness of 0.062" suitable for use with barb style fittings

Non-Wetted Materials Non-Phthalate Polyvinyl Chloride

Wetted Materials Non-Phthalate Polyvinyl Chloride

Clean Room Manufactured Uncontrolled environment

Temperature Range -34.4°C – 65.55°C (-30°F – 150°F)

Working Pressure 3:1 Safety Factor

Operating Range at 25⁰C Vacuum to 7.58 bar (110 psi) at 25°C (75°F)

Diameter Tolerance ± 0.127 mm (± 0.005")

Operating Range at 65⁰C Vacuum to 1.03 bar (15 psi) at 65°C (150°F)

Item Weight 1.18Kg (2.6lb)

ROHS Compliant Yes

Regulatory Information USP Class VI. FDA 21 CFR 177.1592

CE Mark No

REACH Compliant Yes

Other Technical Data Resin compliance is as follows; Phthalate free, DEHP free, Latex free, Conflict minerals free. Animal Derivative free. For further information please email sales@sbrls.com

Disclaimer: All information has been carefully collated and presented, however, SBR-LS cannot accept responsibility for incorrect or misprinted information
